36 Section C - Performance Data
PERFORMANCE DATA
NO LOAD AND NO DOOR OPENINGS AT MID-POINT CONTROL SETTING
Type A with Run/Start Capacitor 85°F (18°C) Ambient 90°F (32°C) Ambient
Operating Time 32 TO 40% 55 TO 65%
Freezer Temperature
0° TO 4°F
-18° to -16°C
-1° TO 3°F
-18° to -16°C
Refrigerator Temperature
34° TO 39°F
1° to 4°C
34° TO 39°F
1° to 4°C
Low Side Pressure (cut-in)
5 to 12 psig
34 to 83 kPa
5 to 12 psig
34 to 83 kPa
Low Side Pressure (cut-out)
-2 to 2 psig
-14 to 14 kPa
-2 to 2 psig
-14 to 14 kPa
High Side Pressure (last 1/3 of cycle)
90 to 115 psig
621 to 793 kPa
130 to 155 psig
896 to 1069 kPa
Wattage (last 1/3 of cycle) 120 to 150 130 to 160
Amps (running) 1.0 to 1.4 1.1 to 1.5
Base Voltage 115 vac (127 vac max) 115 vac (127 vac max)
DEFROST SPECIFICATIONS
Thermostat Heater
Cabinet Size
Cut-In Cut-Out Watts Ohms
23’
25°F
-4°C
47°F
8°C
450 30
Electronic Timer – (ADC) Defros 24 minutes every 6 to 96 hours of compressor run time.
CONDENSER FAN MOTOR
Watts RPM Amps
2.8 950 CW Opposite Shaft .1 Running
ICE MAKER SPECIFICATIONS
Electrical 115 vac (127 vac max)
Thermostat Opens at 48°F (9°C) Closes at 15°F (-9°C)
Heater Wattage 85
ICE MAKER CONNECTOR PLUG CONNECTIONS
Wire Number Wire Color Connects to:
1
Green/Yellow Ground
2
Yellow Water Valve
3
Black Line
4
Light Blue Neutral
