Electrolux T5190LE - 14.2 Drum Area and Air Intake Cleaning

Service Manual
113
14.2 Clean the area around the drum
Disconnect the power to the machine.
Demount the top panel.
Make sure that the area around the drum and the area over the drum are clean and that there is no lint. Clean with a
vacuum cleaner if necessary.
fig.7974
14.3 Air intake, fan house and fan motor
At regular basis, check that the air intake on the front of the machine is not clogged by lint and dust or otherwise
blocked.
Disconnect the power to the machine.
Demount the the back panel.
Remove the screws to the filter (A) and pull out the filter (B).
Clean the fan house from the front of the machine with a vacuum cleaner.
Clean the motor both from the front and back of the machine with a vacuum cleaner.
Be careful not to damage the parts.
fig.8016A
