Electrolux T5190LE - Symbols and Warnings; Technical Data and Drawings

Service Manual
5
1 Symbols
Caution
Caution, hot surface
Read the instructions before using the machine
2 Technical data
2.1 Drawing
fig.8005
1 Operating panel
2 Door opening, ⌀ 400 mm
3 Electrical connection
4 Drain (condensed water)
5
Drain (cooling water)
6 Water connection
