Service Manual
85
13:16 DRUM LOCK POSITION SWITCH
The error code is shown if inputs DRUM UNLOCKED and DRUM LOCKED are both active or inactive at the same
time during positioning sequence. By pressing the start button it is possible to have another trial.
Possible causes:
Heavy unbalance in drum that prevents the motor to position the drum. Worst case scenario is wet load in one com-
partment. Could also depend on problems with indexing sensors, washer I/O board or malfunction in mechanical
drum lock function.
Recommended actions:
1. Check inputs from indexing sensors FC1 and FC2.
2. Run a positioning sequence with wet load in one compartment to test functionality.
MAIN W&D
14:1 EXTRACTION FAILED DRYING ABORTED
Only on Wash & Dryer. If extraction is omitted, the drying sequence will also be omitted.
