18
Service
Manual
Remove
the
belt
around
the
motor
pulley
and
put
the
new
belt
in
position.
fig.8041
Fasten
the
drum
belt.
Make
sure
the
belts
are
in
position.
Remount
the
spring
and
the
drum
belt.
Connect
the
motor
cable
and
remount
the
rear
panel.
9
Heat
pump
unit
9.1
General
fig.W0061
1
1
Grate
2
Fan
3
Evaporation
unit
4
Pressostat
5
Pressostat
17
19
