Service Manual
Error code Text
Major Minor
22
DRUM MOTOR KEB
0
SECURITY INPUT
1
OVERVOLTAGE
2
UNDERVOLTAGE
3
PHASE FAILURE
4
OVERCURRENT
6
OVERHEAT INTERNAL
7
NO OVERHEAT INTERNAL
8
OVERHEAT POWER MODULE
9
DRIVE OVERHEAT
11
NO DRIVE OVERHEAT
12
POWER UNIT
13
POWER UNIT NOT READY
14
POWER UNIT INVALID
15
LOAD SHUNT FAULT
16
OVERLOAD
17
NO OVERLOAD
18
BUS
19
OVERLOAD 2
20
NO OVERLOAD 2
21
EEPROM DEFECTIVE
22
POWER UNIT COMMUNICATION
23
BUS SYNCHRON.
30
MOTOR PROTECTION
31
EXTERNAL FAULT
32
ENCODER 1
33
POWER FACTOR CONTROL
36
NO OVERHEAT POWER MODULE
39
SET
46
PROTECT. ROT. FORWARD
47
PROTECT. ROT. REVERSE
49
POWER UNIT CODE INVALID
Error code Text
Major Minor
23
DRUM MOTOR OBIWAN
1
HEATSINK TOO HOT
2
MOTOR TOO HOT
3
NO INTERLOCK
4
NO COMMUNICATION
5
MOTOR SHORT CIRCUIT
6
INTERLOCK HARDWARE
7
LOW DC VOLTAGE
8
HIGH DC VOLTAGE
255
UNDEFINED ERROR
Error code Text
Major Minor
30
FAN MOTOR COMMON
1
O.H. FAN MOTOR
Error code Text
Major Minor
40
INTERNAL COM.
1–10
I/O INTERLOCK Axxx
11–20
I/O COMMUNICATION Axxx
21
I/O COMMUNICATION
22
I/O BOARD MISMATCH
