5.2.1.1 Control panel configuration
The symbols displayed in the two WM and WD versions can have a symbolic representation and different
positions.
WM WD
The washing programmes, the functions of the selector knob (where featured) and the various buttons
vary according tot he model, since these are determined by the configuration of the appliance.
5.2.1.2 Programme selector (S1)
The selector features 15-21 positions and incorporates the ON/OFF switch. The
various positions of the selector may be configured to perform different washing
programmes (e.g.: water level, drum movement, no. of rinses and the washing
temperature to be selected according to the type of garments). It can be turned
both clockwise and anti-clockwise.
In the first position, the appliance is switched off and the current programme is
cancelled.
For each programme, the compatible options and other parameters are defined.
5.2.1.3 Programme configuration
The table below lists the parameters that can be used to define the washing programmes.
Types of fabric
Cotton/linen, Synthetic fabrics, Delicates, Wool, Hand-wash,
Shoes, Jeans, Duvet, Silk.
Special programmes
Soak, Miniprogramme, Easy-Iron, Conditioner, Rinses, Delicate
rinses, Drain, Delicate spin, Spin, Drying.
Temperature
Normal, Maximum: the initial temperature is the maximum that
can be selected for a specific washing programme
Spin
Normal, Minimum, Maximum
Options (Normal/Possible)
Rinse Hold, Night cycle, Pre-wash, Stains, Bleach, Extra rinse,
Easy-Iron, Economy (energy label), Intensive, Normal, Daily,
Light, Quick, Super quick, Reduced spin speed, No spin, Half-
load.
Programme phases
Pre-wash, Wash, Rinses, Spin, Delayed start, Drying.
