Service
Manual
23
23. Programme unit
18
438 9145-41/03
03.11
I/O-BOARD 1
EMERGENCY STOP
TEMPORARY PAUSE
OIL
REMOTE START
SERVICE
PHASE CHECK
DOOR LOCKED
DOOR CLOSED
UNBALANCE
Press 1.
1
I/O card inputs
I/O-BOARD 2
CHANGE HEATING SYSTEM
REPEAT RINSE
Press 2.
When the programme unit
has two I/O cards:
2
Press any key to go back to
the previous display.
It is now possible to verify the
various input signals from I/O
card 2.
Now you can check the
various input signals from I/O
board 1.
A black square in front of the
name indicates that the input
is active.
Press any key to go back
to the previous display.
SERVICE PROGRAM
LEVEL 2
TEMP 22°C
SPEED 0
DRAIN CLOSED YES
EMERGENCY STOP DOOR LOCKED
TEMPORARY PAUSE DOOR CLOSED
OIL
REMOTE START UNBALANCE
SERVICE
PHASE CHECK
