Service
Manual
23
23. Programme unit
46
438 9145-41/03
03.11
HEATING RELAY ON IF NOT HEATED Y
TEMPERATURE INCREASE ALLOWED Y
LEVEL EMPTY 90
LEVEL OVERFILL 200
PAUSE TEST LEVEL 0
PAUSE TEST TEMPERATURE -18 °C
DEFAULT TEMPERATURE HYSTERIS 4 °C
TEMPERATURE STEP IN COOL-DOWN 4 °C
DEFAULT LOW EXTRACT TIME 00:00
DEFAULT MEDIUM EXTRACT TIME 00:00
DEFAULT HIGH EXTRACT TIME 00:00
DEFAULT DRAIN TIME 00:00
DEFAULT DISTR. TIME 00:00
DO UNBALANCE MEASUREMENT N
DRAIN OPEN DELAY 0:13
START EXTRACT TIME 00:30
ROLLOUT TIME 00:01
PAY PER WASH ALARM 0
LOCK TEST DELAY 0:10
DRAIN TIME WHEN OVERFILL 0:05
OIL LUBRICATION HOURS 100
PULSE TIME OIL LUBR. SEC 0:01
AMOUNT OF I/O MODULES (1-3) 1
DELAY CLEAR DOOR TEXT 04:00
TIMEOUT DRAIN AT PROGRAM START 4:00
TIMEOUT DURING PAUSE 0:00
MINIMUM TEMPERATURE INCREASE 5 °C
DOOR OPEN DELAY FOR MOTOR LOST 1:00
ERROR, NO WATER Y
ERROR, OPEN DOOR Y
ERROR, DOOR LOCK Y
ERROR, LOW TEMPERATURE Y
ERROR HIGH TEMPERATURE Y
ERROR, WATER IN MACHINE Y
ERROR, NO HEAT Y
ERROR, REMAINING WATER Y
ERROR, UNBALANCE SWITCH Y
ERROR, MOTOR COMMUNICATION Y
ERROR, LEVEL ADJUST Y
ERROR, EMERGENCY STOP Y
ERROR, WEIGHT FROM SCALE Y
ERROR, DOOR LOCK SWITCH Y
ERROR, START NOT ALLOWED Y
ERROR, MIS COMMUNICATION Y
ERROR, EWD INTERLOCK Y
ERROR, I/O COMMUNICATION Y
ERROR, LOW OIL LEVEL Y
ERROR, LOW OR HIGH VOLTAGE Y
ERROR, ERROR CODES FROM MOTOR Y
ERROR, PRESS. SENSOR TILT Y
ERROR, PRESSURE SENSOR TIMEOUT Y
ERROR, DOOR SWITCH TILT Y
ERROR, LEVEL OFFSET Y
ERROR, LEVEL SYSTEM NOT CALIB Y
TIME DELAY BEFORE DOOR OPENING 0:30
UPPER TEMPERATURE FOR ERROR 98°C
LOWER TEMPERATURE FOR ERROR -9 °C
MAX ADJUST TEMPERATURE 97 °C
MAXIMUM EXTRACT SPEED 1200
DEFAULT WASH SPEED 48
DISTRIBUTION SPEED 90
DEFAULT LOW EXTRACT RPM 550
DEFAULT MEDIUM EXTRACT RPM 700
DEFAULT HIGH EXTRACT RPM 900
START EXTRACT SPEED 1000
DEFAULT WASH ACCELERATION 20
DISTRIBUTION ACCELERATION 9
EXTRACT ACCELERATION 40
START EXTRACT ACCELERATION 40
EXTRACT RETARDATION 50
MAX SPEED DURING FILLING 100
MAX LEVEL OFFS. FOR AUT. CALIB.
TIME AT DISTRIBUTION SPEED 2
NUMBER OF REDIST LOW 1 UNB.
NUMBER OF REDIST LOW 2 UNB.
NUMBER OF REDIST MEDIUM UNB.
NUMBER OF REDIST HIGH UNB.
NUMBER OF REDIST EXTREME UNB.
DRAIN TIME AT PROG. START
DRAIN TIME AT PROG. END
READY
Variables in Settings 2
When the top line of a menu
is highlighted you have the
option of scrolling down
through the menu faster by
pressing . When you
do, the next portion of the
menu is displayed, with its
last line highlighted.
Confirm changes before you exit Settings 2
If you have changed any of the variables, this
change must be confirmed when you exit Settings
2. To do this you have to use a strap to short-
circuit two terminals on the CPU board, see
section headed "To conclude making changes in
variables under SETTINGS 2".
Answer the questions
using the function key or
the numeric keys.
You can go back and
change a question you
have answered already by
pressing repeatedly.
Press to move on to
the next question.
Different types of question
The questions in the various modules are of two
different types, each of which needs to be
answered in a different way:
Yes/No questions
The function key display shows Y/N , which is
a toggle function (the letter to the right of the
highlighted question toggles between N and Y
each time it is pressed).
Times, temperatures, water levels
To answer these questions, use the numeric
keys. The number of digits required will vary. If
you make a mistake while entering digits,
delete it by pressing ERASE one or more
times.
No confirmation of value entered
Once you have entered the right value, you
simply move on to the next by pressing .
There is no enter or return key to press to
confirm each value.
To alter the value for a question you have
already answered
Press to highlight the question you want,
then simply change the value.
Y/N
HEATING RELAY ON WHEN NOT HEATED Y
TEMPERATURE INCREASE ALLOWED Y
LEVEL EMPTY 90
LEVEL OVERFILL 200
PAUSE TEST LEVEL 0
PAUSE TEST TEMPERATURE -18°C
SETTINGS 2
To Next Page
