Service
Manual
47
23
23. Programme unit
438 9145-41/03
03.11
Y/N
Answer Yes (Y) or No (N).
Press .
HEATING RELAY ON IF NOT HEATED Y
TEMPERATURE INCREASE ALLOWED Y
LEVEL EMPTY 90
LEVEL OVERFILL 200
PAUSE TEST LEVEL 0
PAUSE TEST TEMPERATURE -18 °C
DEFAULT TEMPERATURE HYSTERIS 4 °C
TEMPERATURE STEP IN COOL-DOWN 4 °C
DEFAULT LOW EXTRACT TIME 00:00
DEFAULT MEDIUM EXTRACT TIME 00:00
DEFAULT HIGH EXTRACT TIME 00:00
DEFAULT DRAIN TIME 00:00
DEFAULT DISTR. TIME 00:00
DO UNBALANCE MEASUREMENT N
DRAIN OPEN DELAY 0:13
START EXTRACT TIME 00:30
Heating relay on
Here you determine whether the heating relay will
switch on when heating begins.
Note that the heating relay switches on even if the
answer ”Yes” is in place for the function ”MACHINE
NOT HEATED” (see ”SETTINGS 1”).
If you answer Yes (Y):
The heating relay will switch on when heating
begins. This is the normal sequence in machines
with heating.
If you answer No (N):
The heating relay will not switch on. Used for
machines without heating (not using heating),
which are equipped with a heating relay.
Y/N
Answer Yes (Y) or No (N).
Press .
HEATING RELAY ON IF NOT HEATED Y
TEMPERATURE INCREASE ALLOWED Y
LEVEL EMPTY 90
LEVEL OVERFILL 200
PAUSE TEST LEVEL 0
PAUSE TEST TEMPERATURE -18 °C
DEFAULT TEMPERATURE HYSTERIS 4 °C
TEMPERATURE STEP IN COOL-DOWN 4 °C
DEFAULT LOW EXTRACT TIME 00:00
DEFAULT MEDIUM EXTRACT TIME 00:00
DEFAULT HIGH EXTRACT TIME 00:00
DEFAULT DRAIN TIME 00:00
DEFAULT DISTR. TIME 00:00
DO UNBALANCE MEASUREMENT N
DRAIN OPEN DELAY 0:13
START EXTRACT TIME 00:30
Temperature increase allowed
Here you determine whether or not it will be
possible for the user, during a wash program, to
adjust the wash temperature to a level higher than
the temperature set (this would be done by
highlighting the line ”SET TEMPERATURE” and
entering a different wash temperature).
PROGRAM STEP: MAIN WASH 1
STEP TIME: 720 SEC
SET TEMPERATURE: 85 °C
ACTUAL TEMPERATURE: 21 °C
REMAINING TIME: 70 MIN
DRUM SPEED: 48 RPM
RAPID ADVANCE
PAUSE
SELECT
991 NORMAL 95°C STD
The following functions determine how
temperatures may be changed:
TEMPERATURE INCREASE ALLOWED
If you answer Yes (Y):
This allows the temperature to be changed to a
value which is either higher or lower than the
original ”set temperature” of the wash program.
If you answer No (N):
The only type of change allowed will be to a
value which is lower than the original ”set
temperature”.
Under ”SETTINGS 1” there is the function:
ADJUST TEMPERATURE ALLOWED
which determines whether or not altering the
temperature is allowed at all.
Under ”SETTINGS 2” (i.e. later in this section) there
is the function:
MAX ADJUST TEMPERATURE
which determines the upper temperature limit for
manual temperature adjustment.
