Electrolux W3105H Service Manual

Service
Manual
23
23. Programme unit
48
438 9145-41/03
03.11
HEATING RELAY ON IF NOT HEATED Y
TEMPERATURE INCREASE ALLOWED Y
LEVEL EMPTY 90
LEVEL OVERFILL 200
PAUSE TEST LEVEL 0
PAUSE TEST TEMPERATURE -18 °C
DEFAULT TEMPERATURE HYSTERIS 4 °C
TEMPERATURE STEP IN COOL-DOWN 4 °C
DEFAULT LOW EXTRACT TIME 00:00
DEFAULT MEDIUM EXTRACT TIME 00:00
DEFAULT HIGH EXTRACT TIME 00:00
DEFAULT DRAIN TIME 00:00
DEFAULT DISTR. TIME 00:00
DO UNBALANCE MEASUREMENT N
DRAIN OPEN DELAY 0:13
START EXTRACT TIME 00:30
1 2 3
4 5 6
7 8 9
0
Use the numeric keys to
enter the value.
If you make a mistake while
entering digits:
Press ERASE.
When you have finished:
Press .
HEATING RELAY ON IF NOT HEATED Y
TEMPERATURE INCREASE ALLOWED Y
LEVEL EMPTY 90
LEVEL OVERFILL 200
PAUSE TEST LEVEL 0
PAUSE TEST TEMPERATURE -18 °C
DEFAULT TEMPERATURE HYSTERIS 4 °C
TEMPERATURE STEP IN COOL-DOWN 4 °C
DEFAULT LOW EXTRACT TIME 00:00
DEFAULT MEDIUM EXTRACT TIME 00:00
DEFAULT HIGH EXTRACT TIME 00:00
DEFAULT DRAIN TIME 00:00
DEFAULT DISTR. TIME 00:00
DO UNBALANCE MEASUREMENT N
DRAIN OPEN DELAY 0:13
START EXTRACT TIME 00:30
1 2 3
4 5 6
7 8 9
0
Level empty
Here you determine the water level at which the
drum will be regarded as empty.
It is advisable to set this level so that the inner
drum will have emptied, but so that some water
remains in the outer drum.
If the water has not fallen to this level before the
drain time has ended, the message ”NOT
DRAINED” will appear on the display.
For information on the levels used for the various
machines, see the manual ”Programming, PCS
Program Control Unit”.
Use the numeric keys to
enter the value.
If you make a mistake while
entering digits:
Press ERASE.
When you have finished:
Press .
Level for over-filled drum
Here you determine the water level at which the
drum will be regarded as over-filled.
Over-filling can occur if a water valve is faulty, or if
you have over-filled the machine manually.
For information on the levels used for the various
machines, see the manual ”Programming, PCS
Program Control Unit”.
Under ”SETTINGS 2” (i.e. later in this section)
there are two functions which influence the way the
machine reacts to over-filling:
”DRAIN TIME WHEN OVERFILL”
(i.e. DRAIN TIME AFTER OVER-FILLING)
If you have the answer N (No) inserted for the
function ”ERROR OVER-FILLED” (described
below, this page), the drain valve will open and
discharge water for the time inserted as a
parameter under ””DRAIN TIME WHEN
OVERFILL”. The level will be checked after that,
and the same sequence will be repeated until
the level is back to normal.
ERROR OVER-FILLED
If you answer Y (Yes): if the drum becomes
over-filled, the machine will stop and the error
message ”MACHINE OVER-FILLED” will be
displayed.
If you answer N (No): the drain valve will open
as described above.
