29
29. Door and door lock
10
438 9145-61/06
04.10
Service
Manual
Repairs
Repair work on the machine should only be
done by specially trained personnel.
Emergency opening of door lock
1. Switch off power to the machine by turning the
main power switch to the 0 position.
2. Remove the front cover or top cover. When
replacing the door lock, it is recommended to
remove the front cover.
3. Pull the emergency opening arm to the side.
This retracts the spring-loaded locking pin and
the door lock opens.
Alt. Press down the emergency opening
button.
Fig.
12
5369
12
6111
