Service
Manual
23
23. Programme unit
64
438 9145-41/03
03.11
ERROR, EWD INTERLOCK Y
ERROR, I/O COMMUNICATION Y
ERROR, LOW OIL LEVEL Y
ERROR, LOW OR HIGH VOLTAGE Y
ERROR, ERROR CODES FROM MOTOR Y
ERROR, PRESS SENSOR TILT Y
ERROR, PRESSURE SENSOR TIMEOUT Y
ERROR, DOOR SWITCH TILT Y
ERROR, LEVEL OFFSET Y
ERROR, LEVEL SYSTEM NOT CALIB. Y
TIME DELAY BEFORE DOOR OPENING 0:30
UPPER TEMPERATURE FOR ERROR 98°C
LOWER TEMPERATURE FOR ERROR -9°C
MAX ADJUST TEMPERATURE 97°C
MAXIMUM EXTRACT SPEED 825
DEFAULT WASH SPEED 37
1 2 3
4 5 6
7 8 9
0
ERROR, I/O COMMUNICATION Y
ERROR, LOW OIL LEVEL Y
ERROR, LOW OR HIGH VOLTAGE Y
ERROR, ERROR CODES FROM MOTOR Y
ERROR, PRESS SENSOR TILT Y
ERROR, PRESSURE SENSOR TIMEOUT Y
ERROR, DOOR SWITCH TILT Y
ERROR, LEVEL OFFSET Y
ERROR, LEVEL SYSTEM NOT CALIB. Y
TIME DELAY BEFORE DOOR OPENING 0:30
UPPER TEMPERATURE FOR ERROR 98°C
LOWER TEMPERATURE FOR ERROR -9°C
MAX ADJUST TEMPERATURE 97°C
MAXIMUM EXTRACT SPEED 825
DEFAULT WASH SPEED 37
DISTRIBUTION SPEED 63
1 2 3
4 5 6
7 8 9
0
Time delay before door opening
Here you determine the length of time during which
the door will be prevented from opening if the
machine has detected a fault-error and is displaying
an error message. This must give enough time for
the water to empty and drum speed to be reduced.
Please note that the water will not be emptied as a
result of all types of error. In the case of the HIGH
TEMPERATURE error, for example, the door will
remain locked even though the time you have
programmed has elapsed. One reason for this is to
prevent the risk of a fire if the electrical heating
equipment is still switched on and heating.
Upper and lower temperature limits for errors
Here you determine the temperature limits for the
errors HIGH TEMPERATURE and LOW
TEMPERATURE respectively.
If the HIGH TEMPERATURE error is flagged, this
usually indicates an short circuit in the sensor or
wiring. LOW TEMPERATURE usually indicates a
open circuit in sensor or wiring. That is why the
default value for the low temperature limit is -9 C. If
the sensor cools to this temperature, the resistance
from the sensor will be 0 ohms, which corresponds
to a short-circuit.
Use the numeric keys to
enter the value.
If you make a mistake while
entering digits:
Press ERASE.
When you have finished:
Press .
Use the numeric keys to
enter the value.
If you make a mistake while
entering digits:
Press ERASE.
When you have finished:
Press .
