DOC. NO. 5956.573.05 P. 1 1 / 8 8
Electrolux
EFS - Dishwashing Systems Platform
Electrolux Professional
A4.1.2 GENERIC FUNC.
The GENERIC FUNC. family parameters are selected and edited by using the keys in the same way as that
described for the USER SETTINGS family.
The GENERIC FUNC. family contains parameters that identify several general machine characteristics.
The GENERIC FUNC. family parameters are described below:
(*) For the other equipment families, see par. B PROGRAMMING SHEETS
MODULAR RACK TYPE
COMPACT RACK TYPE
Modular
parameter
Compact
paramet
er
Family
Nr.
Parame
ter Nr.
Parameter description Unit
of
meas
ure
Min Max Factory
setting [for
WTM165 (*)]
Appl. type

1 0 Machine type for modular rack type:
0/Ws Ri : 2 modules rinse and wash.
1/Pw Ws Ri : 3 modules rinse, wash and prewash.
2/Pw Ws Ri Dt: 4 modules rinse, wash, prewash
and DT.
3/Ws Ri Dt: 3 modules rinse, wash and DT.
- - - Ri Ws
(0)
Machine type for compact rack type:
4: Compact pressurized plumbing circuit
5: Compact atmospheric plumbing circuit
6: Compact pressurized plumbing circuit with dt
7: Compact atmospheric plumbing circuit with dt
8: Compact pressurized plumbing circuit with
prewash
9: Compact atmospheric plumbing circuit with
prewash
10: Compact pressurized plumbing circuit with
prewash and dt
11: Compact atmospheric plumbing circuit with
prewash and dt
12: Compact Usa
13: Compact Usa with DT
14: Compact Usa with prewash
15: Compact Usa with prewash and DT
---
Appl.
direct.

1 1 Rack pulling direction (meaningful parameter only
for Modular Rack Type):
1/LEFT: left rack insertion.
0/RIGHT: right rack insertion.
-RIGHT
(0)
LEFT
(1)
RIGHT
(0)
Speed nr.
1

1 2 Indicates gear motor operation frequency at speed
1.
Hz 15 100 27 (**)
Wash time
sp 1

1 3 Time from when the last rack releases the auto
start lever until the wash pumps stop when speed 1
is set
sec 0 127 110
Speed nr.
2

1 4 Indicates gear motor operation frequency at speed
2.
Hz 15 100 51 (**)
Wash time
sp 2

1 5 Time from when the last rack releases the auto
start lever until the wash pumps stop when speed 2
is set.
sec 0 250 58
(**)
Modular machine type WTM140 WTM165 WTM180 WTM200 WTM250 WTM300
(***)
Racks/h Speed nr. 1 80 90 110 130 160 180
Speed nr. 1 25 27 35 40 53 60
Racks/h Speed nr. 2 140 165 180 200 250 300
Speed nr. 2 45 51 58 63 83 100
(**)
Compact machine type RTCS90 / WTCS90 RTCS140 / WTCS140 RTCS180 / WTCS180 RTCS250 / WTCS250
(***)
Racks/h Speed nr. 1 90 90 120 180
Speed nr. 1 27 27 35 57
Racks/h Speed nr. 2 90 140 180 250
Speed nr. 2 27 45 58 80
(***) To comply with Standard DIN 10510 it is advisable to use speed nr. 1
GENERIC FUNC.
