Electrolux WTCS90ERB - A4.1.6 Dt Module

Electrolux
EFS - Dishwashing Systems Platform
Electrolux Professional
DOC. NO. 5956.573.05 P. 2 4 / 8 8
(*) For the other equipment families, see par. .
A4.1.6 DT MODULE
The DT MODULE family parameters are selected and edited by using the keys in the same way as that
described for the USER SETTINGS family.
The DT MODULE family contains the parameters that identify the drying zone (DT) characteristics.
The DT MODULE /  family parameters are described below:
For setting the Standard/0 or New type/1 parameter refer to the tables listed below.
(****)
PREWASH TANKS 600 mm /22” 1165 mm /44” 1490 mm
Tank capacity 45 l 100 l 150 l
Water to drain (in litres/mm) 0,136 l/mm 0,32 l/mm 0,485 l/mm
MODULAR RACK TYPE
COMPACT RACK TYPE
Modular
paramet
er
Compact
parameter
Family
Nr.
Paramet
er
Nr.
Parameter description Unit of
measure
Min Max Factory
setting
Dt
temper.

5 0 Drying tunnel temperature set point. °C / °F 10/
50
90/
194
70/158
Dt hist.
temp.

5 1 Hysteresis temperature relative to the drying tunnel
temperature set point.
°C / °F 0/0 50/
90
3/5
Dt fan
delay

5 3 Time between stop of DT heating element and stop
of DT fan. This parameter ensures a correct cooling
for the DT heating element.
sec 0 250 120
Dt type.

5 4 Indicates the type of DT installed. - Stan
dard
/0
New
type/
1
Standard/
0
DT MODULE
