Electrolux WTCS90ERB - Figure 8 Scheme for H2 C Parameter and B_T Parameter (Only for Compact Rack Type)

DOC. NO. 5956.573.05 P. 1 3 / 8 8
Electrolux
EFS - Dishwashing Systems Platform
Electrolux Professional
.
Modular
parameter
Compact
parameter
Family
Nr.
Para
meter
Nr.
Parameter description Unit
of
mea
sure
Min Max Factory
setting
[for
WTM165
(*)]
Heat two
comm.

1 18 Modular Rack Type:
Wash tank heating element management mode; if set
on “Yes” (1) the two heating elements are managed by
two separate controls, otherwise they are managed by
a single control (See Figure 7 Scheme for “Heat two
comm.” parameter and “Heating manage”
parameter (only for Modular Rack Type)).
-No
(0)
Ye s
(1)
Ye s
(1)
Compact Rack Type:
the mode “1” is not available on compact machines.
-0 1 1
Heating
manage

1 19 Machine heating power management.
Maximum power: the wash tank heating elements
and the boiler heating elements can operate at the
same time.
WARNING:
Check the electrical system and safety
devices ahead of the equipment before set-
ting “Max. power” mode
Medium power: when the boiler heating elements are
on, only one of the two wash tank heating elements
can operate; during the warmup, the tank is heated
first and then the boiler, whereas the boiler has priority
during normal operation.
Minimum power: the wash tank heating elements
cannot operate when the boiler heating elements are
on; during the warmup, the tank is heated first and
then the boiler, whereas the boiler has priority during
normal operation (See Figure 7 Scheme for “Heat
two comm.” parameter and “Heating manage”
parameter (only for Modular Rack Type) and
Figure 8 Scheme for “H2C” parameter and “b_t”
parameter (only for Compact Rack Type)).
Modular Rack Type:
0/“HIGH” = Maximum power
2/“MEDIUM” = Medium power
1/“LOW” = Minimum power
WARNING:
THIS CONFIGURATION CAN ONLY WORK
ON ELECTRICALLY ARRANGED MACHINES
AND THE “Heat two comm.” PARAMETER
MUST BE SET ON “Yes”.
The machines electrically arranged to operate in
“MEDIUM” mode are the WTM165, WTM200
models.
-HIGH
(0)
MEDIUM
(2)
MEDIUM
(2)
Compact Rack Type:
“0” = Maximum power
“2” = Medium power
“1” = Minimum power
WARNING:
THIS CONFIGURATION “2” CAN NOT BE
IMPLEMENTED IN THE ACTUAL VERSIONS
OF COMPACT RACK TYPE.
-0 2 2
