DOC. NO. 5956.573.05 P. 7 5 / 8 8
Electrolux
EFS - Dishwashing Systems Platform
Electrolux Professional
D2.1.2 INVERTER CONTROL TERMINAL ELECTRICAL CONNECTIONS
Figure 15 COMPACT RT Inverter electrical connection
Figure 16 MODULAR RT Inverter electrical connection
D2.1.3 INVERTER PARAMETER LISTS
Schneider Electric Altivar12 type ATV12H055M2
KEY
(1) Blue
(2) Yellow
(3) Black
(4) Brown
(5) Orange
(6) White
(7) Violet
(8) Red
(9) Black
KEY
(1) Brown/ Yellow
(2) Green/ Pink
(3) Blue
(4) Brown
(5) Orange
(6) Black
(7) Grey
(8) White
(9) Black
Mode Family
Sub
family
Param Param Value Default Description




 
def
 
def
 
def
 
modif
 
def
R1A
R1B
R1C
COM
AI1
5V
AO1
LO+
LO-
COM
LI1
LI2
LI3
LI4
+24V
RJ45
(5) (6) (7) (8) (9)
(1) (2) (3) (4)
R1A
R1B
R1C
COM
AI1
5V
AO1
LO+
LO-
COM
LI1
LI2
LI3
LI4
+24V
RJ45
(5) (6) (7) (8) (9)
(1) (2) (3) (4)
