The WASH MODULE family contains the parameters that identify the wash module characteristics.
The WASH MODULE /  family parameters are described below:
MODULAR RACK TYPE
COMPACT RACK TYPE
Modular
parameter
Compact
parameter
Family
Nr.
Param
eter
Nr.
Parameter description Unit of
measure
Min Max Factory
setting
[for
WTM165
(*)]
Wash
module

3 0 Type of wash module
Modular Rack Type:
-0/ “1165” module from 1165 mm
-1/ “1490” module from 1490 mm.
---1490
Compact Rack Type:
- “2” Wash+Rinse module
---2
Stanby
level (**)
(**)
3 1 Indicates the maximum level in the wash tank.
The filling stops when the water level reaches
this level.
mmH2O 60 400 205
Run max
level (**)
(**)
3 2 The value for the maximum level is modified from
“Standby level” to “Run max level” during
washing phase in order to avoid water loss when
the pumps stop.
mmH2O 60 400 170
Drain max
lev. (**)
(**)
3 3 Meaninful only during “Drain and clean” cycle.
Indicates the maximum level during “Drain and
clean” cycle.
mmH2O 60 400 190
Max lev.
hister. (**)
(**)
3 4 Indicates the hysteresis level relative to the
maximum level in the wash tank. It is related to
the “Standby level” to the “Run max level” and to
the “Drain max lev.”.
mmH2O 0 80 30
Working
level (**)
(**)
3 5 Indicates the water level in the wash tank
enabling the wash tank heating elements and the
wash pumps operations.
mmH2O 60 400 90
Tank
temper.

3 7 Tank temperature set point. °C / °F 5/41 90/194 66/151
Sanit.
temper.

3 8 Tank temperature set point during the
sanitization phase (only on machines with
sanitization).
°C / °F 10/50 90/194 75/167
Histesys
temp.

3 9 Hysteresis temperature relative to tank
temperature set point.
°C / °F 0/0 50/90 2/4
Max
Temp.
CU

3 10 Max permissible temperature for the water
leaving the CU to enable heat pump operation. If
the water leaving the CU exceeds this
temperature, the machine continues to work
normally but the heat pump (if present) stops.
WARNING:
Do not modify this parameter unless
expressly required by the factory.
°C / °F 1/34 90/194 50/122
Hist.
Temp.
CU

3 11 Max permissible temperature for the water
leaving the CU to enable heat pump operation: if
the temperature of the water leaving the CU falls
below “Max temp. CU - Hist. temp. CU”, the
machine continues to work normally but the heat
pump (if present) stops.
WARNING:
Do not modify this parameter unless
expressly required by the factory.
°C / °F 1/2 50/90 20/46
WASH MODULE
