Electrolux
EFS - Dishwashing Systems Platform
Electrolux Professional
DOC. NO. 5956.573.05 P. 2 8 / 8 8
Use the increase and decrease keys to move the cursor until it is under the digit to be modified. Press the con-
firm key to modify the selected digit.
The digit flashes and the value of the digit selected can be modified by using the increase and decrease keys.
Press the confirm key to save the new value. Press the accessory functions key to exit without saving.
When all the digits have been modified as required, press the accessory functions key to return to parameter selection mode.
The RATING PLATE family parameters are described below:
(*****) The installer must set the day, month and year of installation.
Parameter
name
Family
Nr.
Para
meter
Nr.
Parameter description Unit of
measu
re
Min Max
Factory
setting
Example
“STRING”
parameter
P.N.C. 70
Product Number Code - - - - 534104 00 Yes
Serial
number
71
Serial number - - - - 54600001 Yes
Model 72
Factory Model - - - - WTM165ERA
+DT
Ye s
Constr. year 73
Year of construction - - - - 2007 Yes
Prod. site 74
Production site (6 = Washing) - 0 10 6 6 Yes
Inst. power 75
Installed power kW - - - 42,3 KW Yes
Voltage
supply
76
Power supply voltage F - - -
AC 400 V 3P N
Ye s
Frequency 77
Frequency Hz 50 60 50 50 Hz No
Max.
current
78
Absorbed current A 6 32 6 65A No
MCA 79
MCA (Minimum supply Circuit Ampacity)
[for USA versions only]
A - - - ----- Yes
MOP 710
MOP (Maximum Overcurrent Protection)
[for USA versions only]
A - - - ----- Yes
Prot. degree 711
Protection rating - IPX5 IPX5 Yes
Inst. day 712
Installation day (*****) - - - - 20 Yes
Inst. month 713
Installation month (*****) - - - - 06 Yes
Inst. year 714
Installation year (*****) - - - - 07 Yes
