P100
User Manual
8
Connect the scanner to a Host through an RS-232 cable with RJ45 and RS-232 connectors and a power
jack:
1) Plug the RJ45 connector into the serial port on the scanner.
2) Plug the RS-232 connector into the RS-232 port on the Host.
3) Plug the supplied power adapter into the power jack on the RS-232 cable.
Power on, Power off and Restart
Power on: power on automatically when the scanner is connected to the host.
Power off: unplug the data cable.
Restart: if the scanner stops responding to input or runs abnormally please re-plug the data cable.
