P100
User Manual
19
VID & PID Table
USB uses 2 numbers to identify the device and find the correct device. The first number is VID
(Supplier ID), designated by USB Implementers Forum. The second number is PID (Device ID), and
each interface type assigns a PID number.
Device Name
Interface Type
PID（Hex）
PID（Decimal）
Scanner
USB virtual serial interface
1f3a
1009
USB virtual keyboard
1f3a
100b
Chapter 3 Scanning Mode
Manual Mode
In manual mode, when the trigger control interface of the scanner changes into trigger electrical level,
the scanner will start to shoot and read. In the limited time of “single reading time”, the scanner will
continuously shoot and read until it is successful. When trigger electrical level is canceled, or read is
over the single read time limit, shooting and reading will be stopped. When read is successful, the
scanner will output the editing content through communication interface. When start a new trigger
read, the host needs to cancel the trigger electrical level at first, and then send the trigger electrical
level after 20ms.
Manual Mode
Sense Mode
In automatic sensing mode, the scanner will monitor the images being taken. When the scene is
changed, it will read within the limited time of “single read time”. After reading the output
information successfully or time out, it will re-enter the state of monitoring scene change.
