Elgin Eagle E Series - General Data and Specifications

D-9
DESCRIPTION
Sweeping paths
One side broom .....................7.5 ft (2286 mm)
Two Side brooms ................... 10 ft (3048 mm)
Water system
Tank capacity.........................280 gal (1060 L)
Filter......................................100 mesh screen
Spray nozzles.....................3 per gutter broom
3 at main broom
Fill hose length ............16 ft 8 in (5.1 m) with
NST coupling
Washdown .................Integral cascade hopper
/conveyor wash
Pump...................Centrifugal, 5 gpm @ 40 psi
Hydraulic system
Pump ........................Three section gear drive
with dual inlet
Capacity ............. 23 GPM (82 L) @1800 RPM
Return filter .....................10 micron, full-flow
with bypass
Breather ............................ 10 micron, spin-on
Inlet strainer.................................... 100 mesh
Reservoir capacity .......................20 gal (76 L)
Electrical system
Alternator .............................95 amp standard
Battery ...................................................12 volt
Brooms
Side broom diameter .............42 in (1100 mm)
Main broom diameter .............35 in (889 mm)
Main broom length................60 in (1524 mm)
Conveyor
Type .........Multiple ply reinforced rubber belt
Speed...................Variable/forward & reverse,
independent of brooms
Flexibility............................9 in oscillation for
large object passage
Lift control ......................................Pneumatic
GENERAL DATA
