M-3
MAINTENANCE
ADDITIONAL Service after 150 hours
(Only for serial numbers up to F999)
Check mast chains for freeness and apply
SAE #30 oil
Grease Chain Rollers
Flush Zirks as required
Check chains for tension
Check carriage and rails for sloppiness.
Reshim if necessary
The numbers below correspond with the locations on
Figures M-1, M-2, M-3 and M-4.
Service after 500 hours
33 Change Hydraulic Oil Reservoir Breather
34 Replace Hydraulic Oil Filter (or per indica-
tor light)
Check Hydraulic Tank Cover Seals
Drain & Flush Hydraulic Oil Reservoir
Refill with new hydraulic oil..
NOTICE
Elgin Sweeper Company recommends Shell Tellus
T-68 or equivalent hydraulic oil.. Use of any fluid
not approved by Elgin Sweeper Company can void
all hydraulic component warranties.
35 Check Side Broom For Wear
Check Main Broom For Wear
36 Check Anti-Freeze - Water Temperature
Gauge
