Procedures to adjust side broom tilt are located in
the Service Procedures Section.
While checking the broom patterns, also check the
dirt shoes (Figure O-5) on each side of the main
broom.
The dirt shoe housings should be flush with the
main broom.
The dirt shoes should be level with the ground.
Procedures for adjusting the dirt shoes are in the
Service Procedures Section.
REVERSING THE CONVEYOR
The conveyor may be reversed, if necessary, for
example, during washdown or if an object is
jammed in the conveyor.
NOTICE
Do not operate the conveyor in reverse for more than
30 seconds. Doing so may cause misalignment of the
conveyor belt and subsequent damage.
To reverse the conveyor, press the 3-position
Conveyor Rotate Switch (#28) to Off and then to
Reverse.
O-17
OPERATION
