DESCRIPTION
D-10
Debris Hopper - SERIES F
Maximum dump height (Bottom of
discharge door)......Up to 9 ft 6 in (2895 mm)
Design lift capacity ..........9,000 lbs (4,080 kg)
Volumetric capacity .............. 4.12 yd
3
(3.2 m
3
)
Material volume..........................3 yd
3
(2.3 m
3
)
Maximum hopper dump angle .................. 45°
Lifting method ....................... Single cylinder,
triple stage mast
Debris Hopper - SERIES E
Maximum dump height (Bottom of
discharge door) .........................26 in (70 mm)
Design lift capacity ........13,500 lbs (6,124 kg)
Volumetric capacity ................ 5.5 yd
3
(4.2 m
3
)
Material volume.......................4.5 yd
3
(3.4 m
3
)
Maximum hopper dump angle .................. 50°
Fuel tank capacity
Standard .................... common 50 gal (190 L)
Auxiliary Engine
Isuzu Diesel Model C-240
Cylinders ............................................4, in-line
Displacement ..........................144 CID (2.3 L)
Horsepower ..............49 HP (40 kW) governed
@ 2500 RPM
Torque.......... 115 lb-ft (156 Nm) @ 2000 RPM
Compression Ratio ................................... 20:1
Bore........................................ 3.39 in (86 mm)
Stroke................................... 4.02 in (102 mm)
Refill capacities
Engine crankcase with filter .....13.5 qt (13 L)
Hydraulic system ...................140 qt (135.2 L)
NOTICE
Elgin Sweeper Company recommends Texaco Rando
HDZ 68 or equivalent hydraulic oil.. Use of any
fluid not approved by Elgin Sweeper Company can
void all hydraulic component warranties.
