7. When adjustment is complete, tighten the jam
nuts.
8. Return conveyor to transport position using
Conveyor Up / Down switch (Figure SP-1, #24).
9. Lower the safety support.
10. Return the hopper to transport position.
DAILY WASHDOWN
A very important step in sweeper maintenance is a
washdown after each run. Use the following proce-
dure in washing the sweeper.
NOTICE
Wash down the machine after every sweeping shift.
1. Park the sweeper on a level surface.
2. Lower conveyor and start rotation using
Conveyor Up / Down (Figure SP-1, #24) and
Conveyor Rotate (#26).
3. Lower the main broom using Main Broom Up /
Down / Rotate (Figure SP-1, #25)
4. Fill the water tank until it overflows, allowing
the water to flush the conveyor belt. This will
SERVICE
PROCEDURES
SP-22
Figure SP-18
Lower Roller Flush Valve
