1. Park the sweeper on a level, paved area.
2. Start the auxiliary engine.
3. Lower the side brooms to the sweeping posi-
tion using Side Broom In / Out (right #5, left -
#1), Side Broom Rotation / Up / Down (Figure
SP-1, right - #6, left - #2).
4. Turn off auxiliary engine.
5. Turn key to ON without starting engine.
6. Place a protractor on the side broom disc and
perpendicular to the side of the sweeper.
7. If the angle is incorrect, loosen the two bolts
securing the motor bracket. Tilt the broom to
the desired angle and tighten the two bolts.
8. Start auxiliary engine.
9. Retract brooms using Side Broom In / Out
(right #5, left - #1), Side Broom Rotation / Up /
Down (Figure SP-1, right - #6, left - #2).
10. Stop auxiliary engine.
NOTICE
This setting will require additional adjustment
when sweeping areas with deep gutters. Best results
are obtained by setting the broom contact pattern at
the location with the unusual gutter configuration.
FRONT-TO-BACK ANGLE
To correct the side broom pattern, if it does not reg-
ister 5° (or desired) front-to-back angle on the pro-
tractor:
1. Park the sweeper on a level, paved area.
2. Start the auxiliary engine.
3. Lower the side brooms to the sweeping posi-
tion using Side Broom In / Out (right #5, left -
#1), Side Broom Rotation / Up / Down (Figure
SP-1, right - #6, left - #2).
4. Turn off auxiliary engine.
SP-15
SERVICE
PROCEDURES
