Before operating the Elgin Eagle, be certain that
you have read and understand all safety and opera-
tion information. If you have any questions, contact
your supervisor before proceeding.
INSTRUMENTS AND CONTROLS
The numbers below refer to those indicated on
Figure O-1 on page O-2.
1 LEFT SIDE BROOM IN / OUT -
Controls movement of the left side broom in
and out. Press switch until broom is fully
extended.
2 LEFT SIDE BROOM UP / DOWN /
ROTATE - Controls up and down movement
and rotation of left side broom. After side
broom is extended (Switch #1), press this
switch forward to lower and rotate the broom.
3 LEFT SIDE BROOM SPRAY WATER
ON / OFF - Turns the spray water at the left
side broom and main broom on and off.
4 LEFT SIDE BROOM LIGHT ON /
OFF - Turns the light at the left side broom on
and off.
5 RIGHT SIDE BROOM IN / OUT
Controls movement of the left side broom in
and out. Press switch until broom is fully
extended.
6 RIGHT SIDE BROOM UP / DOWN /
ROTATE - Controls up and down movement
and rotation of right side broom. After side
broom is extended (Switch #5), press this
switch forward to lower and rotate the broom.
O-1
OPERATION
OPERATION
