If unit is equipped with optional Shutdown
Override to protect from damage due to high
coolant temperature, low engine oil pressure or
low hydraulic oil level, depress the Shutdown
Override Switch (#34, Figure O-1) while start-
ing the engine.
4. Lower the conveyor, using the Conveyor Up /
Down switch (#24).
5. Start conveyor rotation using the Conveyor
Rotate Switch (#26).
6. Lower the main broom, using the Main Broom
Up / Down / Rotate (#25).
7. Move the side brooms out using the Side
Broom In/Out switches (#1 - left, #5 - right).
8. Lower the side broom(s), using the Side Broom
Up / Down / Rotate Switch(es) (#2 - left, #6 -
right).
9. Activate spray water, using the appropriate
Side Broom Spray Water On / Off Switch (right
- #3, left #7).
10. During sweeping, monitor the level of water in
the spray water tank. Sweeping without water
will result in poor dust suppression. The No
Spray Water Indicator will light when the tank
is empty.
OPERATION
O-12
Sweeping Engine
Conditions RPM MPH
Light 2000 8
(15 km/h)
Medium 2250 5 - 8
8 - 15 km/h)
Heavy 2500 1 - 5
(2 - 8 km/h)
Table O-1
General Sweeping Guidelines
