4. Put sweeper into sweep mode, using Sweep /
Transport Circuit Select (#19).
5. Check Tilt Level Indicator (#23) to make sure
sweeper is level. If this indicator light is on,
move sweeper to level ground.
6. Stop rotation of conveyor, main broom and side
broom(s) and raise using
- Conveyor Rotate Switch (#26),
- Conveyor Up / Down (#24)
- Main Broom Rotate / Up / Down (#26)
- Side Broom Rotate /Up / Down Switches
(left - #2, right - #6).
7. Retract side brooms using Left Side Broom In /
Out (#1) and/or Right Side Broom In / Out
Switch (#4).
8. On Series F only, press Hopper up / Down
switch (#27) to raise the hopper to the desired
height
9. If there is room, press Hopper Side Shift
switch (#40) to Out position to move hopper
closer to receptacle.
NOTICE
Before dumping into receptacle, make sure the hop-
per is clear of the top of the receptacle.
10. Use Hopper Dump Switch (#28) to cause the
hopper to dump.
11. After dumping is complete, press Hopper Dump
Switch (#28) rearward to roll back hopper.
12. If hopper was shifted, press Hopper Side Shift
switch (#40) to In position, until hopper returns
to its normal position.
13. On Series F only, press Hopper Up / Down
Switch (#27) rearward to lower hopper.
14. Put sweeper into transport mode, using Sweep /
Transport Circuit Select (#19).
O-19
OPERATION
