EL2315D & EL2316D DOOR
CONTROLLER
USER MANUAL
TABLE OF CONTENTS
1. EL2316D TWO DOOR Controller
1
1.1 INTRODUCTION
1
1.1.1
Keypad / Reader
1
1.1.2
Door Sensor
3
1.1.3
Electric Door Lock
3
1.1.4
Miscellaneous Inputs / Outputs
3
1.2 CARDS
5
1.2.1
Card Features
6
1.2.2
User Cards
6
1.2.3
Special Cards
7
1.3 ACCESS GRANTING
9
2. INSTALLATION
11
2.1 COMMUNICATION OPTIONS
11
2.2 MISCELLANEOUS INPUTS / OUTPUTS
12
2.3 POWER SUPPLY
13
2.4 POWERING UP EL2316D
14
3. ENGINEERING MENU COMMANDS
20
3.1 DOOR MENU
21
3.1.1
Lock Release Time (L-R TIME)
22
3.1.2
Shunt Activation Time
22
3.1.3
Door Sensor
23
3.1.4
Push Button
23
3.1.5
PIN Select
24
3.1.6
PIN Entry
24
3.1.7
Valid Buzzer
24
3.1.8
Door Sensor Debounce
25
3.1.9Exchange Reader (only on EL2315D)
25
3.2 CARD MENU
26
3.2.1
Database Mode
26
3.2.2
TRANSACTION SIZE
27
3.2.3
Card Size
27
3.2.4
Dual Card
27
