Elid EL2315D - Test Keypad; Test Reader

Chapter 3 – Engineering Menu
EL2315D & EL2316D Door Controller Manual
Revision 1.1.21
39
This menu contains 8 diagnostic test routines for checking the
hardware of the controller. The eight commands are displayed in 2
screens as shown below: -
Test
Test
Test
Test
Keyp
Rdr
IN
OUT
|
|
|
|
Test
Test
Test
Test
Keypad
Reader
Input
Output
Use the <#> Key to switch between the 2 screens
Test
Test
Test
Test
Com
7Sg
RAM
ROM
|
|
|
|
Test
Test
Test
Test
Comm.
7-Segment
Memory
Program
3.6.1 Test Keypad
This is for testing the matrix keypad located on the controller, and
not for EK9S reader keypad. The display will show:-
As any key is pressed, its value will be shown on the LCD display.
Press <*> key to exit from this test.
3.6.2 Test Reader
Keypad Test
