Elid EL2315D - Test Input; Test Output

Chapter 3 – Engineering Menu
EL2315D & EL2316D Door Controller Manual
Revision 1.1.21
39
On entering this command, the following display will show:-
You can swipe card on any of the 4 Readers. The display will be as
follows, depending on which reader is used for reading:-
3.6.3 Test Input
On entering this command, the following display will show:-
DS 1
PB 0
S1 0
S2 0
DS 1
PB 0
S3 0
S4 0
The first line of the display indicates the status of the Door Switch
(DS), Push Button (PB), Sensor #1 (S1), and Sensor #2 (S2) for
Door 1, where 0=Contact Open, and 1= Contact Closed.
The second line of the display indicates the status of the Door
Switch (DS) and Push Button (PB), Sensor#1 (S3) and Sensor#2
(S4) for the second door.
3.6.4 Test Output
On entering this command, the following display will show:-
Reader Test
Plse Swipe Card
Reader Test
DOOR #1 123456
Reader Test
DOOR #1(O) 123456
> Output Test <
_
