If Off Output Command is selected, the screen will show: -
|
Output point number
This command allows you to turn off an output.
4.6.3
Set Output Time Zone
The Set Output Time Zone command allows you to program the 6
outputs to be activated automatically according to timer settings.
On entry of this command, the LCD display will show: -
You may choose the timer to be used for each day of the week and
holiday by keying the timer number one at a time. For example, if
output point 1 is connected to a perimeter light which should be
switched on between 6 p.m. and 6 a.m. each night, then according to
the timer setting of Section 4.1.4, timer 06 should be used for every day
of the week, as well as for holidays. Similarly there is another set of
Time Zone for output point # 2 shown on the screen below: -
8 timers may be assigned to it, one for each day.
Note that if timers are not used for any day, the value 00 should be
entered.
