If you wish to use LAN, you need to set the network parameters
using the SET LAN command. When you select the SET LAN
command, the following screen appears.
IP
IP
Gate
Port
Ad
Mask
Way
Addr
You can select any of the 4 settings and modify their values.
IP address
- eg 192.168.1.21
subnet mask
- eg
255.255.255.0
default gateway- eg
192.168.1.1
port address
- eg
4001
Note that you will also need to key in the same values in E.WIN, so
that the PC knows where in the network EL2316D is located.
Please check with the network administrator on what values to set
and key in these values.
3.5.4 Apply LAN Command
The command “APPLY LAN” is for sending the settings to the LAN
module. The new settings you have made using the command
“SET LAN” will be saved in the controller. They are not sent to the
LAN module until the “APPLY LAN” is executed. Therefore, after
you have completed the setting of IP parameters, the last thing to
do is to execute the command “APPLY LAN”.
Press <D> to change the value to YES follow by the <#> key. If
your setting is successful, you will see the following on the screen.
“ Wait …123456789”
3.6 TEST MENU
Set Comm Para
Apply LAN NO
