Chapter 3 – Engineering Menu
EL2315D & EL2316D Door Controller Manual
Revision 1.1.21
28
And you are required to type in the range Card ID numbers that the
controller will recognize as special cards.
If CTYPE is selected, then, whether a card is recognized as special
card or normal user card depends on how the card is encoded.
3.2.7 Continuous Swipe Mode
You can also select whether you want to allow "continuous
swiping" or not. If it is set to yes, it means that you are allowed to
swipe even when the door is open. If the setting is "NO", then the
reading is disabled until the door is closed.
3.3 SENSOR MENU
EL2316D caters for 2 sensor inputs for each door, which may be
programmed for Status Supervision, Alarm Supervision or Interlock
Inhibit.
When Sensor Menu is selected, the following screen appears: -
Ssr
Oprn
Dly
Alm
Typ
Mod
Time
Dur
|
|
|
|
Sensor
Operation
Delay
Alarm
Type
Mode
Time
Duration
There are 2 sensor inputs for each door provided in the controller
that may be connected to a wide range of devices. This menu
allows you to program the method you wish to use to process the
input signals.
3.3.1 Sensor Type
The first command, Sensor Type is accessed by pressing the <A>
