Chapter 3 – Engineering Menu
EL2315D & EL2316D Door Controller Manual
1
Invalid Card
F
Output Off
2
Duress Alarm
G
Exclude Sensor
3
Invalid PIN
H
Include Sensor
4
Door Open Alarm
I
Status On (Sensor #1)
5
Pulse Door Open
J
Status Off (Sensor #1)
6
Invalid Customer Code
K
Door Closed
7
Invalid Time Zone
L
Keypad Locked
8
Anti-Passback Alarm
M
Sensor Alarm (Sensor #2)
9
Valid Entry (OUT)
N
Status On (Sensor #2)
A
Sensor Alarm (Sensor
O
Status Off (Sensor #2)
#1)
B
Sensor Isolation
P
Sensor Isolation (Sensor
(Sensor #1)
#2)
C
Sensor Arming (Sensor
Q
Sensor Arming (Sensor
#1)
#2)
D
Door Left Open Alarm
3.4.3 Output Duration Command
The "OUTPUT DURATION" command is to set the duration for
which the output point is to stay activated when it is set to the
"PULSE" mode. You may set the value from 0 to 999 seconds,
individually for each of the 6 outputs. Note that this command will
only act on a point that has been set to "EVENT" mode (as opposed
to "GP" mode") and to "PULSE" mode (as opposed to "SHRT",
"MULT" or "TOG"). On entering this command, the screen will show:
-
Enter in the desired value and press <#> to accept. Repeat for
Output #2 TO #6.
3.4.4 Example of Using EVENT Mode
Revision 1.1.21
37
Output Duration
1 005 SEC
