2. By timers, set in the command OUTP TZ (Output Time Zone).
3. By EVENTS, which are set in the Engineering Menu.
If you do not desire a point to be time controlled, set all the timers to 0
(which is the default setting). Similarly, if you do not want any event to
affect a point, do not program any event into that point. However, if
time zone and events are both programmed into a particular output
point, then the outcome of that point will be determined by which is the
most recent source that has acted on the point.
Please note that all the outputs should be related to door 1. Thus,
please enter door 1 for each output sub-menu
On selecting the OUTPUT MENU, the following screen appears: -
4.6.1
On Output Command
When the ON OUTPUT Command is selected, the screen will show: -
Output Point Number
You are expected to key in any number from 1 to 6 as there are 6
output points, followed by the <#> Key. The point selected will
immediately turn on. You will be able to see this only if the output
point is connected to some equipment.
4.6.2
Off Output Command
