ELIS PLZEŇ a. s.
Design, Assembly and Service Manual
Page 62 of 69
Electromagnetic flowmeter FLONET FN20xx.1
ELIS PLZEŇ a. s., Luční 425/15, 301 00 Plzeň, Czech Republic, Phone: +420/377 517 711, Fax: +420/377 517 722 Es90420K/c
Position in order number 1 2 3 4 5 6 - 7 8 9 10 11
ORDERING No.: F N 2 0
TYPE IDENTIFICATION
Flange 1
Wafer 2
Non-standard X
ECONOMIC, compact 0
ECONOMIC, remote 1
COMFORT, compact 4
COMFORT, remote 5
TECHNICAL PARAMETERS
6/1 (1/4"/264 ) 0 1
8/1,8 (3/10"/476 ) 0 2
10/2,8 (3/8"/740 ) 0 3
15/6.5 (1/2"/1712 ) 0 4
20/12 (3/4"/3167) 0 5
25/18 (1"/4755) 0 6
32/30 (1 1/4"/7920) 0 7
40/45 (1 1/2"/11887) 0 8
50/72 (2"/19019) 0 9
65/120 (2 1/2"/31697) 1 0
80/180 (3"/47551) 1 1
100/280 (4"/73961) 1 2
125/430 (5"/113590) 1 3
150/650 (6"/171706) 1 4
200/1150 (8"/303756) 1 5
250/1800 (10"/475510) 1 6
300/2520 (12"/665712) 1 7
350/3500 (14"/924391) 1 8
400/4500 (16"/1188774) 1 9
500/7200 (20"/1902039) 2 0
600/10000 (24"/2641932) 2 1
700/14000 (28"/3698514) 2 2
800/18000 (32"/4755096) 2 3
900/23000 (36"/6076062) 2 4
1000/28000 (40"/7397028) 2 5
1200/40000 (48"/10566778) 2 6
Non-standard X X
ČSN EN 1092-1 1
ANSI B 16.5 2
JIS B2210 3
AS 4087 4
Non-standard X
Sensor body and flanges made of carbon steel, polyurethane coating
1
Complete stainless steel 1.4301 2
Non-standard X
Stainless steel 1.4571 1
Hastelloy C-276 2
Platinum - gold platinum 3
Tantalum 4
Titanium Gr.2 ASTM B348-03 5
Non-standard X
Sensor design
Flowmeter
version and
equipment
Dimension of
sensor DN/max
flow rate Q
4
[m
3
/h],
(inch/max flow
rate Q
4
[US G/h])
Sensor flanges
Sensor material,
coating
Electrodes and
grounding rings
material
