Elis FLONET FN20xx.1 Series User Manual

ELIS PLZEŇ a. s.
Design, Assembly and Service Manual
Page 63 of 69
Electromagnetic flowmeter FLONET FN20xx.1
ELIS PLZEŇ a. s., Luční 425/15, 301 00 Plzeň, Czech Republic, Phone: +420/377 517 711, Fax: +420/377 517 722 Es90420K/c
Position in order number 12 13 14 15 16 17 18 19 - 20
Hard rubber (0°C to 80 °C, DN15 to DN1200) 1
Soft rubber (0°C to 80 °C, DN15 to DN1200) 2
Special rubber for drinking water
(0°C to 90 °C, DN15 to DN1200)
3
Teflon PTFE (-20°C to +150 °C, DN15 to DN250) 4
E-CTFE (-20°C to +130 °C, DN300 to DN1200) 5
Non-standard X
Standard IP67 1
Non-standard IP68 – for remote version 2
Sensor to piping 1
Grounding rings 2
Grounding electrode 3
6/150 1
10/150 2
16/150 3
25/300 4
40/600 5
Non-standard X
50 1
80 2
90 3
130 4
150 5
Non-standard X
3 1
6 2
10 3
15 4
20 5
30 6
40 7
50 8
100 9
Non-standard X
230 V AC, 50 Hz to 60 Hz 1
115 V AC, 50 Hz to 60 Hz 2
24 V AC, 50 Hz to 60 Hz 3
24 V AC, DC 4
Non-standard X
No 1
Yes 2
MEASURED MEDIUM
Water 1
Non-standard X
Power supply
Empty pipe
detection
Type of
measured liquid
Sensor lining
Sensor protection
Grounding
Nominal pressure
PN [bar]/psi
[lb/in²]
T
max
liquid [ °C ]
(for compact
version see
chapter 4.1.5)
Length of cable
for remote
version [m]
