ECH 200 BD
18/76
The terminals of the remote keyboard are associated with the following colours:
• 24 Æ blue
• 25 Æ red
• 26 Æ black
Be cautious when connecting these terminals because they are reversed against the connector’s terminals.
5.4 Parameter programming – Menu levels
Device parameters may be modified using a Personal Computer (with the required software, interface module and cables),
or using the keyboard.
If using the keyboard, access to parameters is arranged in a hierarchy of levels which may be accessed by pressing the
“mode and “on-off” keys at the same time (as described above).
Each menu level is identified by a mnemonic code which appears on the display.
