18.4.1 PCInterface interface module
This device enables the controller to interface with the PC.
Æ For information on how to connect the device, see the Param Manager Manual.
Æ For information on the technical specifications of PCI2150, see the instruction sheet.
The PC must be connected with the interface module, and the interface module with the device, with no power
on to any of the devices, and in compliance with current safety regulations. It is also important to avoid
electroshocks, especially on the open metal surfaces of each unit. It is therefore necessary to adopt special
measures to convey electrostatic currents to the ground.
18.5 Sonde
A
D
B
C
A: Humidity probe EWHS280: dimensions 103x25 mm.
B: Humidity probe EWHS300: dimensions 80x80x52 mm.
C: Pressure probe EWPA007
D: Temperature probe NTC
PCI2150
