ECH 200 BD
49/76
Minimum value of proportional fan control during cooling. Expressed as a percentage of the maximum permitted voltage,
from 0 to 100%,.
Maximum silent speed during cooling
Maximum value of proportional fan control during cooling. Expressed as a percentage of the maximum permitted voltage,
from 0 to 100%,.
Minimum fan speed temperature/pressure set point during cooling
Condensation pressure/temperature value below which the fan runs at minimum cooling speed.
Proportional band during cooling
Temperature/pressure differential corresponding to change from minimum to silent maximum fan speed during cooling.
Cut-off differential
Condensation temperature/pressure differential within which fan continues to run at low speed.
Cut-off hysteresis.
Condensation temperature/pressure differential for fan cut-off.
Cut-off bypass time
Determines the amount of time after fan start-up during which compressor cut-off is excluded. Expressed in seconds.
Maximum speed during cooling
May be used to set a speed step corresponding to a given temperature/pressure value during cooling.
Maximum fan speed temperature/pressure set point in cooling mode
Condensation temperature/pressure value corresponding to the fan speed set for par. F13.
Minimum speed during heating
Minimum proportional fan control value in heating mode. Expressed as a percentage of the maximum permitted voltage,
from 0 to 100%,.
Maximum silent speed during heating
Maximum value of proportional fan control during heating. Expressed as a percentage of the maximum permitted voltage,
from 0 to 100%,.
Minimum fan speed temperature/pressure set point during heating
Condensation temperature/pressure value above which the fan operates at minimum speed in heating mode.
Proportional band during heating
Temperature/pressure differential corresponding to a change from minimum to maximum silent fan speed during heating.
Maximum speed during heating
May be used to set a speed step corresponding to a given temperature/pressure value during heating.
Maximum fan speed temperature/pressure set point during heating
Condensation temperature/pressure value corresponding to the fan speed set for par. F19.
Internal fan step differential
May be used to set a temperature differential between one step of fan control and the next for internal fan control.
Internal fan step hysteresis
May be used to set a hysteresis for each fan control step cut-off.
Not used
Not used
Preventilation in cooling mode
May be used to set a preventilation time in cooling mode before the compressor is turned on.
11.1.4 Alarm parameters (ALL)
Low pressure pressure switch bypass time.
Determines the delay between starting up the compressor and starting up the low pressure digital alarm diagnostics.
Expressed in seconds.
Low pressure alarm events per hour
Used to set the number of low pressure digital alarm events per hour beyond which the system will switch from automatic
reset to manual reset.
Bypass flow switch after pump on
Determines the delay between activation of the hydraulic pump and activation of the flow switch alarm diagnostics.
Expressed in seconds.
Duration of active flow switch input
May be used to set the amount of time for which the flow switch digital input must remain active to generate a flow
switch alarm. The timer starts after the flow switch by-pass time. Expressed in seconds.
Duration of inactive flow switch input
May be used to set the time for which the flow switch digital input must remain inactive to be included in the
corresponding alarm. Expressed in seconds.
Number of flow switch alarms/hour
May be used to set the number of flow switch digital alarms per hour after which the alarm is switched from automatic to
manual reset. When this occurs, the hydraulic pump is deactivated.
Compressor thermal switch bypass following compressor on
Determines the delay between compressor activation and activation of the compressor thermal switch digital diagnostics
alarm. Expressed in seconds.
Compressor 1/2 thermal switch alarm events per hour
May be used to set a number of compressor thermal switch alarm events per hour beyond which the alarm is switched
from automatic to manual reset..
Fan thermal switch alarm events per hour
May be used to set a number of fan thermal switch alarm events per hour beyond which the alarm is switched from
automatic to manual reset.
Anti-freeze alarm by-pass
Determines the delay between turning on the machine and activation of the anti-freeze alarm; it is enabled only in the
heating mode. Expressed in minutes.
Anti-freeze
alarm set point
May be used to set the temperature below which the anti-freeze alarm is triggered.
Anti-freeze alarm differential
May be used to set the anti-freeze alarm differential.
Anti-freeze alarm events per hour
May be used to set a number of anti-freeze alarm events per hour beyond which the alarm is switched from automatic to
manual reset.
Pa F07
Pa F08
Pa F09
Pa F10
Pa F11
Pa F12
Pa F13
Pa F14
Pa F15
Pa F16
Pa F17
Pa F18
Pa F19
Pa F20
Pa F21
Pa F22
Pa F23
Pa F24
Pa F25
Pa A01
Pa A02
Pa A03
Pa A04
Pa A05
Pa A06
Pa A07
Pa A08
Pa A09
Pa A10
Pa A11
Pa A12
Pa A13
