A: power supply
B: control signal
Always work on connections using a NOT powered instrument. Operations must be performed by qualified
personnel.
18.1.3 CF modules: mechanical assembly
Power boards are supplied for the back-of-board installation.
The different board model dimensions are listed in the following diagram:
Connection
diagram
1 2 3
4 5
7 6
CF-REL
B
A
32 31 30 29
N4 N3 N2 N1 F4 F3 F2 F133 34 35 36
28 27 26 25 24 23 22 21
N6 N5
(max 500 Watt)
A
B
CF-05
32 31 30 29
N4 N3 N2 N1 F4 F3 F2 F133 34 35 36
28 27 26 25 24 23 22 21
N6 N5
(max 1.500 Watt)
A
B
CF-15
32 31 30 29
N4 N3 N2 N1 F4 F3 F2 F133 34 35 36
28 27 26 25 24 23 22 21
N6 N5
(max 2.200 Watt)
A
B
CF-22
