Eliwell ECH 200BD "Adaptive" - Installation; Connection Diagrams; Configuration of Analogue Inputs

ECH 200 BD
7/76
Model ECH 210 BD ECH 215 BD
Circuits 1 1
Compressors (in chiller) 2 2
Compressors (in heat pump) 1 2
Application
Stages 1 1
Relays (2A 230 V~) 4 5
Triac (2A 230 V~) 1
Digital input 5 5
Analog output
Input/output
Analog input 4 4
Srew connectors • •
Remote keyboard • •
Remote on-off • •
Heat pump control • •
Defrost • •
Condensing pressure control • •
Water pump control • •
Electric heater • •
Dynamic set point • •
Features
Water free cooling • •
Water flow alarm • •
High pressure alarm • •
Low pressure alarm • •
Thermal compressor alarm • •
Thermal fan alarm • •
Antifreeze alarm • •
Diagnostic
High water temperature alarm • •
Base parameters
tabel
