Elmo MX-P3 - Specification; Main Camera Technical Specifications

33
➓ SPECIFICATION
◆MAIN CAMERA
Item
Specifications
Power source
DC5V
Power consumption
2.5W (when connecting USB)
6.0W (when connecting HDMI/RGB)
Outside dimensions
W: 343 mm D: 82 mm H: 302mm (When setup)
W: 290 mm D: 82 mm H: 22mm (When folded)
Weight
Approx. 460g (Main body only)
Ext. control terminal
USB2.0 Type C × 1
Lens
F=2.0
Frame rate
60fps (in high frame rate mode at 1080p)
Focus working range
From lens surface：100 mm ～ ∞
Focus
Auto (One-push)
Exposure
Auto (Possible to adjust exposure level)
Image pick-up element
1/3.1 inch CMOS 13,000,000 pixels
Effective pixels
H: 4160, V: 3120
Resolution
H: 1300 TV lines or more V: 1300 TV lines or more
Digital zoom
Max. 16x
Imaging area
374 mm × 281 mm (Height：286 mm) 4：3
HDMI resolution
4K (2160p), 1080p, 720p
RGB resolution
1080p, XGA
Simultaneous output
Possible from each port (USB/HDMI OUT/RGB OUT）
◆FUNCTIONAL SPECIFICATION
Item
Specifications
Oper
ating
pane
l
IM+
C
IM4
EIT
Brightness
adjustment
Possible (Settable in 7 levels)
Default setting: 9
✔
-
✔
✔
Image rotation
0°/180° Default setting: 0°
(The image rotation function is not available
when the image freeze function is used.)
✔
LED lighting
ON/OFF Default setting: OFF
✔
-
-
-
AF（focus）
Manual (One-push)
✔
-
-
-
Zoom
Possible (from x1 to x16)
Default setting: x1
✔
Image pause
Possible
✔
