RG - Recorder Gap
Purpose:
Defines the frequency per sampling times that the recorder is activated.
Because the recorder has a limited storage capacity, if it operates at the sampling time of
the drive, the recorder will operate for a very short time. For longer recording times, the
time interval between consecutive data recordings must be increased. The RG parameter
trades recording resolution against recording time. With RG=1, the sampling time of the
recorder is WS[29]. Be aware that recorder sampling time depends on the TS value and
the specific unit mode (UM).
Attributes: Type: Parameter, Integer
Source: Program, RS-232, CANopen
Restrictions: Recorder inactive (RR=0 or RR=-1)
Default value: 1 (RS), Non-volatile
Range: [1…4096]
Unit modes: All
Activation: Next initiation of the recorder (RR)
If the drive has stored a previously recorded data vector, setting RG will invalidate
this data. Invalidated data cannot be retrieved.
See also:
RC, RL, RP[N], RR, BH, TS, WS[29], UM
Reference chapter in the
SimplIQ Software Manual:
Chapter 7.4, ”The Recorder”
