51&AVRprog
programmed device from the ZIF socket. Incorrectly placed
device in the ZIF socket can cause its damage or destruction.
Technical specification
HARDWARE
Socket, pin drivers and DACs
• 40-pin DIL ZIF (Zero Insertion Force) socket accepts both
300/600 mil devices up to 40-pin
• specialized GND/VCC/VPP pindriver for MCS51 and AVR
devices
• TTL driver provides H, L and read for all needed pins
DEVICE SUPPORT
• microcontrollers 51 series: 87Cxxx, 87LVxx, 89Cxxx, 89Sxxx,
89LVxxx series from Atmel, Intel, Philips, ... 20/40 pins
• microcontrollers Atmel AVR: AT90Sxxxx series (parallel
mode), 8/20/40 pins
• serial E(E)PROM: 24Cxxx, 24Fxxx, 25Cxxx, 59Cxxx, 85xxx,
93Cxxx series
Notes:
• Serial EEPROMs programming is performed little bit slowly.
• Hardware of 51&AVRprog programmer isn't capable to
support some latest MCS51/AVR chips.
• For all supported devices see actual Device list on
www.elnec.com.
SOFTWARE
• Algorithms: only manufacturer approved or certified
algorithms are used.
• Algorithm updates: software updates are available approx.
every 2 weeks, free of charge.
• Main features: revision history, session logging, on-line help,
device and algorithm information
Device operations
• standard:
• blank check
• read
• program
• verify
• erase
• configuration and security bit program
• security:
89
