PIKprog+
• 40-pin DIL ZIF (Zero Insertion Force) socket accepts both
300/600 mil devices up to 40-pins
• two D/A converters for VCCP and VPP, controllable rise and
fall time
• VCCP range 0..7V/250mA
• VPP range 0..15V/150mA
• pindriver: 40 TTL pindrivers, special GND/VCC/VPP pindriver
for PICmicro® devices
• spare GND, VCC and VPP driver, which add additional
made-by-wire GND/VCC/VPP pin capability for future devices
• FPGA based TTL driver provides H, L, CLK, pull-up, pull-
down on all pindriver pins
• level H selectable from 1.8 V up to 5V
• in-circuit serial programming (ISP) capability included
• continuity test: each pin is tested before every programming
operation
• selftest capability
• autocalibration
ISP connector
• 10-pin male type with missinsertion lock
• 6 TTL pindrivers, provides H, L, CLK, pull-up, pull-down; level
H selectable from 1.8V up to 5V to handle all (low-voltage
including) devices.
• 1x VCCP voltage (range 2V..7V/100mA) and 1x VPP voltage
(range 2V..25V/50mA)
• programmed chip voltage (VCCP) with both source/sink
capability and voltage sense
DEVICE SUPPORT
Programmer, in ZIF socket
• microcontrollers MicrochipTM PICmicro®: 12xxx, 14xxx,
16xxx, 17xxx and 18xxx series, 8 to 40 pin (*1), parallel and
serial mode
• Serial E(E)PROM: 24Cxxx, 24Fxxx, 25Cxxx, 59Cxxx, 85xxx,
93Cxxx series
Programmer, through ISP connector
• Microcontrollers Microchip PICmicro: PIC12Cxxx, PIC16C5x,
PIC16Cxxx, PIC17Cxxx, PIC18Cxxx series
Notes:
• (*1) - suitable adapters are available for non-DIL packages
and devices with more than 40 pins
• For all supported devices see actual Device list on
www.elnec.com.
