Section 1. Features and Specifications
3
SPECIFICATIONS
Table 1-2 lists the specifications for the Port Powered Swipe Reader. Figure 1-3 shows the
dimensions for the standard product. Other sizes are available by special order.
Table 1-2. Specifications
OPERATING
Reference Standards ISO/ANSI/ CDL/ AAMVA*
Power Input From RS-232 interface
Recording Method Two-frequency coherent phase (F2F)
Message Format ASCII
Card Speed 3 to 50 IPS
MTBF Electronics: 125,000 hours. Head: 1,000,000 passes
ELECTRICAL
DTR Voltage 5 to 15 VDC
Current
Quiescent
Transmitting
Peak at Power On
1 to 2 mA typical (continuous)
8 to 9 mA typical (5 ms duration)
12 mA
RS-232 Communication 9600 bps, no parity, 8 data bits, 1 stop bit
MECHANICAL (STANDARD PRODUCT)
Dimensions Length: 3.94” (100.0 mm),
Width: 1.28” (32.5 mm)
Height: 1.23” (31.3 mm)
Weight Reader 5.8 oz. (165 gr.)
Cable length 5 Ft. (1.5 m)
Connector 9 pin D female (May require a 25-pin adapter)
ENVIRONMENTAL
Temperature
Operating 32
o
F to 131
o
F (0
o
C to 55
o
C)
Storage -22
o
F to 158
o
F (-30
o
C to 70
o
C)
Humidity
Operating 10% to 90% noncondensing
Storage Up to 100% noncondensing
Altitude
Operating 0-10,000 ft. (0-3048 m.)
Storage 0-50,000 ft. (0-15240 m.)
* ISO (International Standards Organization), ANSI (American National Standards Institute), CDL
(California Drivers License), and AAMVA (American Association of Motor Vehicle Administrators).
